Galeo Pro
Actions
Vascular Intervention // Coronary
Coronary Guide Wire
Galeo® Pro
Galeo Pro
Indicated to facilitate the placement of interventional cardiology catheters.1
Technical Data
| Guide Wire | |
|---|---|
| Diameter |
0.014" |
| Length |
190 cm and 300 cm |
| Core wire material | High tensile stainless steel |
| Proximal coil | 21.5 cm, stainless steel |
| Distal coil | 26 mm, palladium, radiopaque |
| Proximal (shaft) coating |
PTFE |
| Distal coating | Hydrophilic (30 cm) |
| Range of tip flexibilities | High flexible (HF), flexible (F), medium (M) |
| Range of support levels | Standard and Extra Support (ES) |
| Shaft markers | 92 cm and 102 cm from distal end |
Ordering Information
| - | - | |||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 406886 | Straight | High flexible | Red | Standard | 190 cm | |||||||||
| 406887 | Straight | Flexible | Orange | Standard | 190 cm | |||||||||
| 406888 | Straight | Medium | Blue | Standard | 190 cm | |||||||||
| 406889 | Straight | Flexible | Yellow | Extra Support | 190 cm | |||||||||
| 406890 Galeo EW (Extension Wire) | - | - | Purple | - | 150 cm | |||||||||
Contact
Indication as per IFU.
