DX Technology


Atrial Fibrillation Management Solution for Single-Chamber ICD Patients

Atrial fibrillation (AF) is a widespread, often silent problem for implantable cardioverter-defibrillator (ICD) patients, occurring at an annual incidence of nearly 21%.1 Unfortunately, it is difficult or even impossible to detect with a standard, single-chamber ICD.1 If AF remains untreated, a patient’s clinical condition may worsen, potentially resulting in severe outcomes.

This is where DX Technology comes in. By providing atrial sensing capabilities, DX Technology addresses the shortcomings of single-chamber ICDs. It is the only single-lead ICD system able to provide AF management diagnostic data originating directly from the atrium – and this is what makes it truly unique.


Tachycardia ICD

Product Highlights

Icon DX Technologie

Detect AF Early

DX ICDs increase the likelihood of detecting atrial arrhythmias early, helping you to identify patients at risk and ensure prompt, appropriate patient management

DX Technology - AF Management Solution; Monitor AF Burden Reliably

Monitor AF Burden Reliably

The DX ICD system helps you monitor AF burden over time3 so that you can intervene when needed, react to changes in patient status and optimize treatment

DX Technology - AF Management Solution; Improve Outcomes Effectively

Improve Outcomes Effectively

Once AF is detected and its burden monitored, appropriate therapy, when needed, can be initiated in a timely manner for improved clinical outcomes9

Unparalleled Single-Lead ICD Technology

Available as a unique, single-lead ICD system equipped with a floating atrial dipole, DX ICDs offer reliable, timely information about atrial arrhythmias and detect AF early.2, 3, 4, 5, 6 After detection, the system helps you monitor AF burden over time.3

It can be paired with the proven BIOTRONIK Home Monitoring® platform, and complemented with the BIOTRONIK Patient App. In combination, this AF management solution offers a comprehensive assessment of ICD patients and enables earlier, well-informed decision-making.

Clinical Evidence

Detect AF Early

  • Direct, true atrial signal thanks to the DX tachycardia lead enhanced with a floating atrial dipole.
  • Long-term, stable atrial sensing (24-month follow-up).2, 3, 4
  • It is almost four times more likely to detect atrial tachyarrhythmia (AT)/AF with DX ICD than with a standard single-chamber ICD in patients without a history of atrial arrhythmias at implant.2, 6, 7
  • Reliable detection and transmission of atrial high-rate episodes (AHREs) with clinically relevant duration (for AHRE ≥1 hour, positive predictive value (PPV) >99.7%).3
  • Real-world data for DX ICD patients over a two-year follow-up period shows Home Monitoring messages are transmitted for 90.2% of patients.3 Among these, messages are transmitted on 92.5% of days (median value).3

Monitor AF Burden Reliably

  • DX ICD allows correct estimation of AF burden with reliable classification of AHRE episodes by their duration (6min–1h, 1h–24h, and ≥24h).3
  • DX ICD helps clinicians adhere to the AF European guidelines on AHRE monitoring and initiate oral anticoagulant (OAC) treatment for stroke prevention in a timely manner.9
  • DX ICD offers decision support for therapeutic interventions such as initiation of antiarrhythmic drugs or AF ablation, proven to reduce symptoms and improve cardiovascular outcomes.9,10

Improve Outcomes Effectively

  • Incidence of OAC prescription onset tends to be higher with DX ICDs compared to standard single-chamber ICDs.2
  • Associated with lower stroke incidence compared to single-chamber ICDs, DX ICDs have been shown to help avoid 4.6 strokes per year per 1,000 patients.1
  • By helping to avoid strokes, DX ICDs save costs compared to single-chamber ICDs in patients with a CHA2DS2-VASc score >5, with the highest savings for patients with a CHA2DS2-VASc score of 9.1,*
  • An 81% reduction of nonactionable clinic visits12 and a 21% reduction in the number of hospitalizations11 can be achieved by incorporating BIOTRONIK Home Monitoring into the AF management workflow.
  • The BIOTRONIK Patient App allows patients to be more engaged in their care and integrates them into their disease management, an approach that can foster improved health awareness and behavior.13
  • Furthermore, it adds patient-reported data to enable joint rhythm and symptom evaluation and provides faster notification of patient symptoms for quicker reaction to changes in a patient’s condition.

Key Studies

More Than a Decade of Clinical Experience

DX Technology Related Information

More Than a Decade of Clinical Experience

DX Technology boasts a long-standing history of clinical experience and a vast body of clinical evidence. Since 2009, over 100,000 implantations¹⁴ have been performed in more than 80 countries¹⁴, supported by over 20 clinical studies involving more than 4,000 patients.¹⁵

This strong foundation of clinical evidence has recently been enriched by the MATRIX study results, the largest clinical evaluation of DX Technology to date.³
clinical studies
study patients
devices implanted


  • In an unselected, real-life setting, the study results confirm that DX Technology, combined with BIOTRONIK Home Monitoring, allows for reliable, guideline-recommended remote monitoring of subclinical AF.3
  • The clinical relevance of AHRE monitoring is underlined by the fact that patients with new-onset AHRE often experience AHRE progression and are at substantial risk of thromboembolic events, while most of them are not on OAC.3
Adjudication Outcome for the First AHRE


  • The THINGS registry results show that DX systems are associated with an almost fourfold likelihood of detecting AT/AF compared to a standard, single-chamber ICDs.2
  • The diagnosis of AT/AF often leads to clinical interventions, mainly represented by OAC onset.2


  • The SENSE study results show that the DX ICD system may offer significant benefits for AHRE detection in ICD patients who do not have an atrial pacing indication, but are at high risk of developing subclinical AF.7
AHRE Detection


Dr. George Thomas, Principal Investigator of the SENSE study, on DX Technology and AHRE detection.
Selecting the Right ICD - To aid in the selection of the ICD device type to be implanted, Dr. Mate Vamos from the University of Szeged, Hungary, together with a panel of experts, recently introduced a helpful ICD selection flowchart.
